Glass facade with LED elements

Unique LED illuminated solar façade for an innovative company in Austria

May 2016 - SUNOVATION, manufacturer of functional glass for architectural applications, is manufacturing the solar facades for the new Omicron headquarters in Vorarlberg in the company's colours.

Austrian company Omicron planned for its head office in Vorarlberg an innovative and sustainable facade in its blue, red and yellow logo colours. For this purpose, a very elegant glass facade with blue as the main colour has been designed with high-efficiency embedded solar cells.

The multifunctional glass elements are custom-made. For the exclusive design, colourful solar cells have been combined with special coloured glass, creating an architecturally sophisticated and colourfully homogenous surface. This is only opened by the specific structure of the solar cells and their reflections, through which an interesting contrast is created. A special highlight of the energy-producing designer facade is the integrated LED colour display in the company colours. At night, this highlights the facade spectacularly and reflects the affinity for technology and innovative power of the company. "With this solution, we have created a sensational and unique facade for our customer, as unique as the business itself," says Stefan Koch, head of product management at SUNOVATION Produktion.

In total, the facade consists of 510 glass-glass modules and 90 LED glass elements that are specially authorised for vertical installation in the facade. The substructure consists of an extruded section measuring approx. 1,000m and over 1,200 retaining brackets, embedded in the wooden wall. The design as a "structural glazing" bonded joint enables a frameless suspension of the glass elements on the retaining profile that are each suspended at 4 points in so-called "bolt slides" in the substructure. The total production and installation time for this 780m² curtain wall took around 6 months.

Construction information:

Client: OMICRON electronics GmbH, Klaus, Austria
Architect: Dietrich | Untertrifaller Architketen, Bregenz, Austria
Facade elements: SUNOVATION Produktion GmbH
Facade: 780 m²
Photovoltaic facade elements: 510 units
LED glass elements: 90 units
Nominal electrical capacity 92 kWp
Calculated yearly energy output 66,000kWh/anno

New production site

SUNOVATION Produktion is increasing its production capacity and modernising its manufacturing processes

Dezember 2015 - Since 2015, the company has been supplying customers throughout the world from its new production site in Aschaffenburg, Germany.

Because of increased international demand, the old production sites had reached its capacity limits. Since 2015, the company has been supplying customers throughout the world from its new production site in Aschaffenburg, Germany.

This site has ideal transport links and it is situated logistically conveniently in the Greater Frankfurt area. As well as production, logistics and administration units have also been integrated within the production site. The glass module manufactory has an area of approx. 2,100m², around 300m² of which are for glass preparation and 200m² for the soldering of solar cells.

"As well as the pure capacity increase, there has also been a comprehensive modernisation of the machinery," says managing director Heribert Ley. Production orders can therefore be implemented more efficiently, faster and with a higher level of quality. "We are delighted that other customers, because of the new factory as well, see us as a leading supplier in our market segment," he continues.

Currently, the yearly production capacity is 48,000m² for flat glass-glass modules and 40,000m² for curved glass-glass modules. Around 75 people are employed at the Aschaffenburg site. The regionally ingrained company has consciously left its new production site in the Bavarian Lower Main region. Existing jobs could therefore be maintained and new ones could be created.

BIPV project with curved glass-glass modules

SUNOVATION realizes project with curved SUNOVATION eFORM Crystal

BIPV-Projekt mit ebenen und gebogenen Photovoltaik-Fassadenelementen SUNOVATION eFORM Crystal

SUNOVATION, manufacturer of solar elements for architectural applications, equips a new office building in passive-plus-energy house standard with individual glass-glass modules for the integration into buildings.

The new building of the AZV Erdinger Moos, designed by Architekturwerkstatt Vallentin, excels through its futuristic design and the combination of down-to-earth and innovative materials. One remarkable design element are the 84 m² striking, individually designed photovoltaic facade elements, which have been attached to the railings of the floating corridor in intervals of 2 m. A total of 26 glass-glass modules Sunovation eFORM Crystal with polycrystalline, blue solar cells were installed. The solar elements with a size of 3.25 m² have a capacity of 454 Wp each.

One particular feature of the semi transparent BIPV modules is the finishing of the rear side of the modules by means of selective screen-print. By imitating the front cell optics, the module surface visible from the inside ideally integrates itself into the design concept. The highlight, however, are the two curved photovoltaic elements on the curved structure of the triangular shaped atrium. The approximately 3m² large glass-glass modules are bent in a radius of approximately 3.5m. By means of their adaptive design, they perfectly harmonize with the building line and optimally blend into the overall design.

Glass-glass modules of the Sunovation eFORM series are exclusively manufactured project-specifically. Architects and planners have thus various design possibilities for a perfect integration of these solar building elements. Available are individual sizes, shapes, cell- and module colors. The modules can be supplied semi-transparent, homogeneous monochrome as well as contrasting in almost every color.

The new building at Erdinger Moos was carried out in minimal-energy construction with an extremely heat-insulating envelope, comfort ventilation system and photovoltaic systems in the facade and on the roof.

Product innovation BIPV

Individual art solar power module for building integration SUNOVATION eFORM art

– Beispiel eines Kunst-Solarmoduls zur Gebäudeintegration. Realisierung in Zusammenarbeit mit Glasmalerei Peters. Künstlerische Gestaltung: Bavo Tiebos

SUNOVATION, manufacturer of solar power modules for architectural applications shows extraordinary possibilities for a unique facade design.

The individual art solar power modules are tailor-made versions of the glass glass module series Sunovation eFORM. The special Sunovation manufacturing process enables the production of these extravagant modules. By means of a cold filling process, crystalline solar cells are embedded between two glass sheets. This allows an individual determination of size, geometry, cell coverage and color range.

The support plates of the art modules are finished in a wide variety of glass processing techniques according to customers’ specifications in cooperation with a renowned workshop for glass design. For combining art and solar power the artistically designed glass sheets are assembled to individual solar power modules. This includes a free choice of cells and its layout adapted to the overall synthesis of the art.

Any designs ranging from traditional to abstract art up to the presentation of company logos are realizable. The Sunovation eFORM artline allows very individual artistic accents to be set in architecture. Art solar power modules are particularly suitable for parts of representative buildings.

SUNOVATION is a producer of solar construction elements for applications in architecture. The project-specific SUNOVATION solar power modules are ideal for contemporary construction projects. They are used as solar façades, solar canopies or shading solutions. In the field of e-Mobility, special Car- and BikePort systems that combine flexibility with exclusive design are provided. Due to the special technology, building elements can be individually produced in terms of geometry, solar cells, degree of transparency and color range.

SUNOVATION researches, develops and produces in Elsenfeld. From the location in Germany, close to Frankfurt/Main, SUNOVATION supplies customers worldwide who are looking for special architectural solutions.

Product innovation BIPV

Monochrome glass-glass modules for building integration - SUNOVATION presents Sunovation eFORM Color at the exhibition BAU 2013

SUNOVATION, manufacturer for architectural applications, brings homogenous monochrome glass-glass modules for facade design on the market.

The solar modules SUNOVATION eFORM Color are an innovative further development of glass-glass solar modules for building integration. The special feature of these building elements is the uniform appearance in homogenous, monochrome optic. With this product, photovoltaic can be integrated exclusively into buildings. SUNOVATION eFORM Color are currently available in the colors black, anthracite, cobalt blue, gold and silver.

For the special design, matching colored solar cells are put into a group with colored special glasses – also the current-carrying connectors between the solar cells are the same shade of color. The surface is only interrupted by the specific structure of the solar cells and its reflections from different viewing angles. According to viewing angle and model, it is often only apparent at a second glance, that it is a photovoltaic module. These modules are just as powerful as conventional glass-glass modules for building integration. Through the application of crystalline solar cells efficiency levels of up to 18% are reached. The modules are produced up to a size of 3.500 x 1.500 mm according to customers’ requirements.

The design of the overall project is clearly the focus here –the integrative optic of the monochrome glass-glass modules open up new design possibilities. „With our new product line we are taking our customers’ request fro homogenous and at the same time very precious building elements for building integration “, states Heribert Ley, CEO of SUNOVATION GmbH. Facades on representative buildings can be equipped with this procuts either entirely or partially. Also a play with different module colors as well as the combination of solar building elements with matching glass elements is possible. Furthermore, a backlighting with LEDs is possible with these new solar power elements.

SUNOVATION eFORM Color in the colors black and blue.

The SUNOVATION GmbH is a manufacturer of solar building elements for architectural applications. The project-specific solar modules are ideally suitable for modern building projects. They are used, for example, as solar facades, solar roofs or shading solutions. In the area of e-mobility flexible solutions with an exclusive design are offered with the specially designed car- and bikeport systems. Due to the patented production technology, building elements can be manufactured individually in terms of shape, cell coverage, level of transparency and coloring.

SUNOVATION researches, develops and produces in Elsenfeld/Main. Form the facility in Germany, close to Frankfurt, customers looking for special architectural solutions are delivered worldwide.
